Stand-alone automatic/manual control:ATX,P¢ó,P¢ô,S.P.S.and S.P.S.
power.
Can save 10 sets of load,circulate test dynamic automaticly.
Mainframe
power voltage:AC 110/AC 220V selectable, AC power of S.P.S is supplied
by external AC;or supplied by inside AC 110V/AC 220V,can be selected
by panel switch.
S.P.S
AC input voltage¡¢current¡¢power¡¢power factor,efficiency test.(AUTO10+
only) |
|
6 sets of load(4 pos.and 2 neg.,or
customize according to customer)
| Group |
+VA |
+VB |
-VC |
-VD |
+VE |
+VF |
| Current Range |
0 ¡« 40A |
0 ¡« 4A |
0 ¡« 20A |
0 ¡« 4A |
| Voltage Range |
0 ¡« (40 ¡« 80)V |
0 ¡« 40V |
| maximum Power |
200W |
30W |
100W |
30W |
| Over power(15S) |
300W |
|
150W |
40W |
|
| |
|
|
|
| |
Test
function£º
Test automaticly and display 6 sets of load direct current voltage.
Hi/Lo voltage
limit setting for 6 sets of load direct current voltage.
Test and display power comsuption of each 6 sets of load.
Short protection test of 6 groups of voltage.
OPP single key testing can set parameter manually, display power
comsuption or total comsuption of each groups.
Can test boot-strap time of Setup¡¢PG Ring¡¢P.G and turnoff time of
Hold On¡¢PF Ring¡¢P.F.
BNC port can be selected by rolling wave-band switch,work in oscillograph
etc.(options),test the wave shape of eac(RIPPLE&NOLSE).
Built-in
PS¡ªON/OFF function.
Provide ATX/AT Power standard tooling,or customize special tooling
according to customer.
Test and display S.P.S input AC voltage/current.
INT/EXT select S.P.S. as input power,inside select AC 110V or AC
220V,three sets of external AC input can be used by AC Line Regulation
when testing.
Measure S.
P.S apparent power, active power , power factor, Efficiency built-in,
leave out outer power meter when S. P.S tests. ( suitable for TR-
368AUTO+ type); |
|
Option£º
Oscillograph¡¢power
form¡¢Frequency conversion power¡¢Resistance load test panel¡¢Electronic
load test panel¡¢Safe testing system.
|
| |
